Technical Parameters
Item | C180 | C200 |
POWERTRAIN | ||
Engine brand model | YTO | YTO |
Number of cylinders | 6 | 6 |
Rated engine speed | 2200 r/min | 2200 r/min |
Rated power | 180 hp | 200 hp |
TRANSMISSION | ||
Clutch | 14 in, dry, dual action | 14 in, dry, dual action |
Shift mode | Sliding gear/synchronizer with shuttle gear | Sliding gear/synchronizer with shuttle gear |
Number of gears | 16F+8R | 16F+8R |
Four-wheel drive control | Mechanical | Mechanical |
Differential lock | Mechanical | Mechanical |
Brake form | wet, disc type | wet, disc type |
PTO spline & speed | 6/8 keys; 760/850 | 6/8 keys; 760/850 |
TIRES | ||
Front wheels | 14.9–26 | 14.9–26 |
Rear wheels | 18.4–38 | 18.4–38 |
Optional wheels | 460/85R38–380/85R28; 520/85R38–420/85R28 | 460/85R38–380/85R28; 520/85R38–420/85R28 |
IMPLEMENT & HYDRAULICS | ||
Lifter control type | Position control, floating adjustment | Position control, floating adjustment |
Number of multiway valves | 3 | 3 |
DIMENSIONS & WEIGHT | ||
Dimensions | 5310×2325×3000 mm (CAB) | 5310×2325×3000 mm (CAB) |
Wheelbase | 2720 mm | 2720 mm |
Ground clearance | 440 mm | 440 mm |
Structural mass | 5150 kg (CAB) | 5150 kg (CAB) |
The DONOL DN-C Series brings DONOL tractors into the 140–200HP power class. Built around a newly tuned heavy-duty chassis, the series provides greater stability, traction and operating capability for large farms and professional agricultural contractors.
Representative models include the 180HP DONOL DN-C180 and the 200HP DN-C200. The DN-C200 is the first DONOL tractor model to reach the 200HP level, marking an important step in the development of the DONOL high-horsepower tractor range.
New-Generation DONOL Chassis
The DN-C chassis is developed for higher engine power and heavier field loads. A 2,720 mm wheelbase and 5,150 kg structural mass create a stable operating platform for large implements and intensive cultivation.
The 440 mm ground clearance improves mobility across uneven farmland. Large 14.9–26 front and 18.4–38 rear tyres provide a strong contact area, while optional radial tyre combinations are available for different traction and soil requirements.
Six-Cylinder DONOL Power
DONOL DN-C180 and DN-C200 tractors are powered by six-cylinder YTO diesel engines rated at 2,200 r/min. The engine configurations provide 180HP and 200HP for heavy ploughing, soil preparation, seeding and transport applications.
A 14-inch dry dual-action clutch transfers power through a 16F+8R transmission. Synchronised shifting and shuttle gear provide practical speed selection and convenient directional control.
Heavy-Duty DONOL Configuration
Mechanical four-wheel drive and a differential lock help maintain traction in loose soil and demanding field conditions. Wet disc brakes provide dependable braking performance during heavy operation and transport.
The rear PTO offers six- or eight-spline options with 760/850 r/min speeds. Position control, floating adjustment and three multiway hydraulic valves support a broad selection of agricultural implements.
The DONOL DN-C Series is suitable for:
Large-scale ploughing and cultivation
Deep tillage and soil preparation
Large seeders and fertilising equipment
Heavy farm transport
Hay and grassland operations
Professional agricultural contracting
With power up to 200HP, a newly tuned chassis and proven mechanical systems, the DONOL DN-C Series provides a strong and dependable tractor solution for large-scale agriculture.
